ARG23012

anti-CD16 antibody [DJ130c]

anti-CD16 antibody [DJ130c] for Flow cytometry,IHC-Formalin-fixed paraffin-embedded sections,IHC-Frozen sections and Human,Macaque

Developmental Biology antibody; Immune System antibody; General Lymphocyte Marker Study antibody; Natural killer cells antibody

Overview

Product Description Mouse Monoclonal antibody [DJ130c] recognizes CD16
Mouse anti Human CD16 antibody, clone DJ130c recognizes human CD16, also known as Low affinity immunoglobulin gamma Fc region receptor III-A or Fc-gamma RIIIa. CD16a is a 254 amino acid ~50-65 kDa single pass type 1 transmembrane glycoprotein bearing two Ig-like C2 type domains. CD16 exists as a transmembranous form (Fc gammaRIIIA, or CD16A) and a glycosyl phosphatidylinositol (GPI) anchored form, Fc gammaRIIIB, or CD16B (Scallon et al. 1989). CD16A is expressed by NK cells, some T cells, and macrophages, whereas CD16B is primarily expressed by granulocytes (Ravetch and Perussia 1989). In addition, CD16B exists as two allelic variants NA1 and NA2 . DJ130c recognizes all polymorphonuclear cells irrespective of their NA phenotype.Mouse anti Human CD16 antibody, clone DJ130c recognizes an epitope in the first membrane-distal domain of CD16, recognizes both CD16a and CD16b and has been demonstrated to cross-react with CD16 from rhesus macaques, Macaca mulatta (Xu et al. 2012)
Tested Reactivity Hu, Macaq
Tested Application FACS, IHC-Fr, IHC-P
Host Mouse
Clonality Monoclonal
Clone DJ130c
Isotype IgG1
Target Name CD16
Antigen Species Human
Conjugation Un-conjugated
Alternate Names FCRIIIA; FcRIIIa; CD antigen CD16a; Fc-gamma RIII-alpha; FCR-10; FcR-10; FCRIII; FCG3; Low affinity immunoglobulin gamma Fc region receptor III-A; FCGRIII; CD16; Fc-gamma RIIIa; IgG Fc receptor III-2; IMD20; CD16A; IGFR3; CD16a antigen; FCGR3; FcRIII; Fc-gamma RIII

Application Instructions

Application Suggestion
Tested Application Dilution
FACSAssay-dependent
IHC-FrAssay-dependent
IHC-P5 - 10 µg/ml
Application Note IHC-P: Antigen Retrieval: Boil tissue section in Sodium citrate buffer (pH 6.0).
FACS: Use 10 µl of the suggested working dilution to label 10^6 cells in 100 µl.
* The dilutions indicate recommended starting dilutions and the optimal dilutions or concentrations should be determined by the scientist.

Properties

Form Liquid
Purification Purification with Protein G.
Buffer PBS and 0.09% Sodium azide
Preservative 0.09% Sodium azide
Concentration 1 mg/ml
Storage Instruction For continuous use, store undiluted antibody at 2-8°C for up to a week. For long-term storage, aliquot and store at -20°C or below. Storage in frost free freezers is not recommended. Avoid repeated freeze/thaw cycles. Suggest spin the vial prior to opening. The antibody solution should be gently mixed before use.
Note For laboratory research only, not for drug, diagnostic or other use.

Bioinformation

Database Links

GeneID: 2214 Human FCGR3A

Swiss-port # P08637 Human Low affinity immunoglobulin gamma Fc region receptor III-A

Gene Symbol FCGR3A
Gene Full Name Fc fragment of IgG, low affinity IIIa, receptor (CD16a)
Background This gene encodes a receptor for the Fc portion of immunoglobulin G, and it is involved in the removal of antigen-antibody complexes from the circulation, as well as other other antibody-dependent responses. This gene (FCGR3A) is highly similar to another nearby gene (FCGR3B) located on chromosome 1. The receptor encoded by this gene is expressed on natural killer (NK) cells as an integral membrane glycoprotein anchored through a transmembrane peptide, whereas FCGR3B is expressed on polymorphonuclear neutrophils (PMN) where the receptor is anchored through a phosphatidylinositol (PI) linkage. Mutations in this gene have been linked to susceptibility to recurrent viral infections, susceptibility to systemic lupus erythematosus, and alloimmune neonatal neutropenia. Alternatively spliced transcript variants encoding different isoforms have been found for this gene. [provided by RefSeq, Jul 2008]
Function Receptor for the Fc region of IgG. Binds complexed or aggregated IgG and also monomeric IgG. Mediates antibody-dependent cellular cytotoxicity (ADCC) and other antibody-dependent responses, such as phagocytosis. [UniProt]
Highlight Related products:
CD16 antibodies; CD16 ELISA Kits; CD16 Duos / Panels; Anti-Mouse IgG secondary antibodies;
Related news:
Tumor-Infiltrating Lymphocytes (TILs)
Research Area Developmental Biology antibody; Immune System antibody; General Lymphocyte Marker Study antibody; Natural killer cells antibody
Calculated MW 29 kDa
PTM Glycosylated. Contains high mannose- and complex-type oligosaccharides. Glycosylation at Asn-180 is mandatory for high affinity binding to the Fc and for discrimination between fucosylated and afucosylated IgG glycoforms.
The soluble form is produced by a proteolytic cleavage.

Images (2) Click the Picture to Zoom In

  • ARG23012 anti-CD16 antibody [DJ130c] FACS image

    Flow Cytometry: Human peripheral blood lymphocytes stained with ARG23012 anti-CD16 antibody [DJ130c].

  • ARG23012 anti-CD16 antibody [DJ130c] IHC-P image

    Immunohistochemistry: Formalin-fixed and paraffin-embedded Human spleen tissue stained with ARG23012 anti-CD16 antibody [DJ130c] at 5 - 10 µg/ml dilution. Antigen retrieval: Heat-induced.
