anti-B Raf antibody [G11-G]

anti-B Raf antibody [G11-G] for IHC-Formalin-fixed paraffin-embedded sections and Human,Mouse,Rat

publication_link Publication1


Product Description Rabbit Monoclonal antibody [G11-G] recognizes B Raf
Tested Reactivity Hu, Ms, Rat
Tested Application IHC-P
Host Rabbit
Clonality Monoclonal
Clone G11-G
Isotype IgG
Target Name B Raf
Antigen Species Human
Immunogen Synthetic peptide around Val600 of Human B-raf. (corresponds to Val637 of Mouse or Rat B-raf).
Conjugation Un-conjugated
Alternate Names BRAF1; v-Raf murine sarcoma viral oncogene homolog B1; Proto-oncogene B-Raf; p94; Serine/threonine-protein kinase B-raf; RAFB1; EC; B-RAF1; NS7

Application Instructions

Application Suggestion
Tested Application Dilution
IHC-P1:100 - 1:200
Application Note * The dilutions indicate recommended starting dilutions and the optimal dilutions or concentrations should be determined by the scientist.


Form Liquid
Buffer 20 mM Tris-HCl (pH 8.0), 0.05% Sodium azide and 20 mg/ml BSA
Preservative 0.05% Sodium azide
Stabilizer 20 mg/ml BSA
Storage Instruction For continuous use, store undiluted antibody at 2-8°C for up to a week. For long-term storage, aliquot and store at -20°C or below. Storage in frost free freezers is not recommended. Avoid repeated freeze/thaw cycles. Suggest spin the vial prior to opening. The antibody solution should be gently mixed before use.
Note For laboratory research only, not for drug, diagnostic or other use.


Database Links

GeneID: 109880 Mouse BRAF

GeneID: 673 Human BRAF

Swiss-port # P15056 Human Serine/threonine-protein kinase B-raf

Swiss-port # P28028 Mouse Serine/threonine-protein kinase B-raf

Gene Symbol BRAF
Gene Full Name B-Raf proto-oncogene, serine/threonine kinase
Background This gene encodes a protein belonging to the raf/mil family of serine/threonine protein kinases. This protein plays a role in regulating the MAP kinase/ERKs signaling pathway, which affects cell division, differentiation, and secretion. Mutations in this gene are associated with cardiofaciocutaneous syndrome, a disease characterized by heart defects, mental retardation and a distinctive facial appearance. Mutations in this gene have also been associated with various cancers, including non-Hodgkin lymphoma, colorectal cancer, malignant melanoma, thyroid carcinoma, non-small cell lung carcinoma, and adenocarcinoma of lung. A pseudogene, which is located on chromosome X, has been identified for this gene. [provided by RefSeq, Jul 2008]
Function Protein kinase involved in the transduction of mitogenic signals from the cell membrane to the nucleus. May play a role in the postsynaptic responses of hippocampal neuron. Phosphorylates MAP2K1, and thereby contributes to the MAP kinase signal transduction pathway. [UniProt]
Calculated MW 84 kDa
PTM Phosphorylation at Ser-365 by SGK1 inhibits its activity.
Methylation at Arg-671 decreases stability and kinase activity.
Ubiquitinated by RNF149; which leads to proteasomal degradation. Polyubiquitinated at Lys-578 in response to EGF.

Images (2) Click the Picture to Zoom In

  • ARG10554 anti-B Raf antibody [G11-G] IHC-P image

    Immunohistochemistry: Formalin-fixed and paraffin-embedded Human epithelium and stromal cells in normal bowel mucosa tissue (4 µm sections) stained with ARG10554 anti-B Raf antibody [G11-G].

  • ARG10554 anti-B Raf antibody [G11-G] IHC-P image

    Immunohistochemistry: Formalin-fixed and paraffin-embedded Human nuclei of basal cell carcinoma of the skin and dermal fibroblasts tissue (4 µm sections) stained with ARG10554 anti-B Raf antibody [G11-G].

Specific References

BRAF V600E mutant colorectal cancer cells mediate local immunosuppressive microenvironment through exosomal long noncoding RNAs

WB / Human

Jie Zhi et al.
World J Gastrointest Oncol.,  (2022)
