ARG30333

M1/M2/TAM Marker Antibody Panel

Component

Cat No Component Name Host clonality Reactivity Application Package
ARG10514 anti-CD68 antibody [KP1] Mouse mAb Hu, Ms, Rb, Rat FACS, ICC/IF, IHC-P, IHC-Fr, IHC-FoFr , WB 20 μg
ARG56509 anti-iNOS antibody Rabbit pAb Hu, Mamm, Ms, Rat ICC/IF, IHC-P, IP, WB 50 μl
ARG55554 anti-CD206 / MMR antibody [15-2] Mouse mAb Hu, Ms CyTOF®-candidate, FACS, FuncSt, ICC/IF, IHC-Fr, IP, WB 20 μg
ARG66630 anti-CD163 antibody [SQab19148] Rabbit mAb Hu IHC-P 20 μl

Overview

Product Description M1/M2/TAM Marker Antibody Panel is an all-in-one solution to make identification of macrophage subtypes easy and economic. This antibody panel comprises M1 macrophage markers CD68 and iNOS antibodies, and M2 macrophage markers CD163 and CD206 antibodies. Besides, all four antibodies are ideal for determining the tumor-associated macrophage (TAM) phenotype. All the antibodies in this panel have excellent IHC staining performance. Also, the different host species make double staining possible.
Target Name M1/M2/TAM Marker
Full Name Antibody Panel for M1/M2/TAM Marker
Alternate Names M1/M2/TAM Marker antibody; CD68 antibody; CD206 / MMR antibody; iNOS antibody; CD163 antibody

Properties

Note For laboratory research only, not for drug, diagnostic or other use.

Bioinformation

Gene Full Name Antibody Panel for M1/M2/TAM Marker
Highlight Related news:
New antibody panels and duos for Tumor immune microenvironment

Images (9) Click the Picture to Zoom In

  • ARG56509 anti-iNOS antibody WB image

    Western blot: Raw264.7 cells untreated or treated with LPS. 20 µg of cell lysates stained with ARG56509 anti-iNOS antibody at 1:400 dilution.

  • ARG10514 anti-CD68 antibody [KP1] IHC-P image

    Immunohistochemistry: Formalin-fixed and paraffin-embedded Human tonsil stained with ARG10514 anti-CD68 antibody [KP1]. Antigen Retrieval: Boil tissue section in Citrate buffer (pH 6.0).

  • ARG55554 anti-CD206 / MMR antibody [15-2] IHC-Fr image

    Immunohistochemistry: Frozen section of Human tonsil tissue stained with ARG55554 anti-CD206 / MMR antibody [15-2] at 1:25 dilution. The antibody stains endothelia of lymph vessels strongly.

  • ARG56509 anti-iNOS antibody IHC-P image

    Immunohistochemistry: Paraffin-embedded Human pancreatic ductal adenocarcinoma stained with ARG56509 anti-iNOS antibody.

  • ARG66630 anti-CD163 antibody [SQab19148] IHC-P image

    Immunohistochemistry: Formalin/PFA-fixed and paraffin-embedded Human liver tissue stained with ARG66630 anti-CD163 antibody [SQab19148]. Antigen Retrieval: Heat mediation was performed in Tris/EDTA buffer (pH 9.0).

  • ARG10514 anti-CD68 antibody [KP1] WB image

    Western blot: Human Macrophages and N1 Fibroblast untreated or treated with N-glycosidase F. The blots were stained with ARG10514 anti-CD68 antibody [KP1].

  • ARG10514 anti-CD68 antibody [KP1] FACS image

    Flow Cytometry: THP1 cells prefixed with 4% PFA and then permeabilised with 0.25% saponin. Cells were stained with ARG10514 anti-CD68 antibody [KP1] (white area) or isotype control antibody (gray area).

  • ARG10514 anti-CD68 antibody [KP1] IHC-P image

    Immunohistochemistry: Formalin-fixed and paraffin-embedded Human breast carcinoma stained with ARG10514 anti-CD68 antibody [KP1].

  • ARG10514 anti-CD68 antibody [KP1] IHC-P image

    Immunohistochemistry: Paraffin-embedded Mouse kidney stained with ARG10514 anti-CD68 antibody [KP1] at 1:200 dilution.

    Secondary antibody: Anti-Mouse IgG antibody (Rhodamine red).
